C7 Z06 Stage 4 | Factory LT4

The valvetrain opens up here. Custom billet camshaft, dual valve springs, Kong-ported blower, full exhaust, and a calibration that accounts for all of it. Stage 4 is where the LT4 gets the sound people recognize and the power numbers that back it up. This is not a bolt-on build.

Estimated power gain: +150 to 170 rwhp. Estimated peak: ~800 to 820 rwhp. Calibrated with HP Tuners and VR RTD.

Fitment: 2015 to 2019 C7 Z06 (LT4) only.

Fuel: 93 octane pump gas.

What's included

Induction & Airflow
RotoFab Big Gulp Cold Air Intake
Nick Williams 103mm Gen V LT Throttle Body (Black)

Supercharger
Kong Performance Billet High-Flow VR LT4 Water Manifold
Kong Performance CNC Porting of Supercharger and Snout (ZPE Hub, 2.5" Pulley)

VR Cam Kit
Vengeance Racing Custom Camshaft (38% fuel lobe upgrade)
BTR .660" Lift Dual Valve Spring Kit with Titanium Retainers
Vengeance Racing 3/8" Hardened Pushrods
IWIS Pro Series Seamless Roller Timing Chain
CHE High Performance Trunnion Kit
BTR VVT Phaser Limiter (Gen 5 LT)
GM Gen V VVT Cam Bolt
GM Crank Bolt
Johnson 2110R Drop-In Hydraulic Lifters
GM Lifter Trays
GM MLS 6.2L Head Gaskets
GM LT Exhaust Gaskets
DOD Delete Plug Kit
ARP Cylinder Head Bolt Kit
GM LS Front Cover Seal

Oil System
Katech Gen V LT High-Capacity Dry Sump Oil Pump

Pulleys & Drive
ATI Dry Sump Balancer Kit (crankshaft bolt included)
DSX Tuning 9.45" Lower Pulley (bolts included)
Gates Green HD 8-Rib Supercharger Belt

Exhaust
Kooks 2" Stainless Long Tube Headers with 3" X-Pipe and GREEN Catalytic Converters
Vengeance Racing Header Bolt Kit

Fuel System
DSX Tuning Auxiliary Fuel Pump System (320lph)

Cooling
AMP Billet Thermostat Housing (160°)

Crankcase
Mighty Mouse Wild Catch Can System (AN lines and fittings included)

Ignition
NGK LTR7IX Iridium Spark Plug Set
Vengeance Racing 8.65mm Spark Plug Wire Set

What the Full Package covers

The Full Package is not parts plus labor. It is a complete, calibrated, running car handed back to you. On top of every part listed above, the installed price includes:

• Professional installation of all listed hardware
• Supercharger and snout sent out for CNC porting and returned
• All required fluids (engine oil, filter, coolant) and used-fluid recycling
• Complete ECU calibration, calibrated with HP Tuners and VR RTD
• Baseline and final dyno testing, with a before and after printout
• All HP Tuners licensing and ECU credits
• Full street and dyno tuning session
• 10 gallons of 93 octane fuel
• Complete four-wheel alignment
• Shop supplies and interior and exterior protection throughout the build
• Vengeance Racing limited warranty
• Wash and vacuum before delivery

Parts Only ships you the hardware. The Full Package is that same hardware installed, tuned, and running before it leaves the shop.

Parts Only (shipped)

Parts Only ships the complete hardware kit to your door. The CNC porting on this package is a send-in service, so your supercharger and snout ship to our machining partner and back. That freight is already included in the price. Installation, tuning, fluids, and calibration are not included. Shipping on your hardware kit is calculated at checkout.

Available add-ons

• 2017+ automatic transmission tuning (required for 2017 and newer automatic cars): +$650
• 2017+ ECU licensing credits (required for 2017 and newer vehicles): +$100
• Torque converter upgrade, Circle D Pro-Series (strongly recommended at Stage 4 and above, contact for pricing)

A deposit holds your build slot

$500 deposit at checkout. Balance due at drop-off. Questions before booking? Contact us.
